Optinis jungiamasis laidas EFB O0361.1 (LC-ST, OS2, SM 9/125, Duplex, LSZH, 1 m)
Optinis jungiamasis laidas EFB O0361.1 (LC-ST, OS2, SM 9/125, Duplex, LSZH, 1 m)
- Tipas: Tinklo kabelis (patch)
- Izoliacija: LSZH
- Ilgis: 1 m
- Gamintojas: EFB
- Produkto kodas: O0361.1
- Technines specifikacijos
- Anti-kink sleeveput-on, put-on, put-on, put-on
- Bend optimized fiberno, no, no, no
- Cable structureDuplex, Duplex, Duplex, Duplex
- Cable typeI-V(ZN) H, I-V(ZN) H, I-V(ZN) H, I-V(ZN) H
- Cable Ø2 mm, 2 mm, 2 mm, 2 mm
- CategoryOS2 G652D, OS2 G652D, OS2 G652D, OS2 G652D
- Colour outer sheathyellow, yellow, yellow, yellow
- Fibre typeSinglemode 9/125, Singlemode 9/125, Singlemode 9/125, Singlemode 9/125
- Flame retardantacc. to IEC 60332-1-2, acc. to IEC 60332-1-2, acc. to IEC 60332-1-2, acc. to IEC 60332-1-2
- Halogen freeacc. to IEC 62821, acc. to IEC 62821, acc. to IEC 62821, acc. to IEC 62821
- Insertion loss 1310nm≤0,15 dB, ≤0,15 dB, ≤0,15 dB, ≤0,15 dB
- Jacket materialLSZH, LSZH, LSZH, LSZH
- Low smokeacc. to IEC 61034, acc. to IEC 61034, acc. to IEC 61034, acc. to IEC 61034
- Min. Bending radius (Dynamic)> 20xOD mm, > 20xOD mm, > 20xOD mm, > 20xOD mm
- Min. Bending radius (Static)> 10xOD mm, > 10xOD mm, > 10xOD mm, > 10xOD mm
- Number of fibers2, 2, 2, 2
- Operating Temperature-20 – 60 °C, -20 – 60 °C, -20 – 60 °C, -20 – 60 °C
- PackagingEFB-Electronics poly bag (resealable), EFB-Electronics poly bag (resealable), EFB-Electronics poly bag (resealable), EFB-Electronics poly bag (resealable)
- ReinforcmentAramid, Aramid, Aramid, Aramid
- Return loss 1310nm≥45 dB, ≥45 dB, ≥45 dB, ≥45 dB
- Return loss 1550nm≥45 dB, ≥45 dB, ≥45 dB, ≥45 dB
- Scope of delivery1x Patchcable, 2x Duplex Clip, 1x Measurement Report, 1x Information Sheet, 1x Patchcable, 2x Duplex Clip, 1x Measurement Report, 1x Information Sheet, 1x Patchcable, 2x Duplex Clip, 1x Measurement Report, 1x Information Sheet, 1x Patchcable, 2x Duplex Clip, 1x Measurement Report, 1x Information Sheet
- Storage Temperature-20 – 70 °C, -20 – 70 °C, -20 – 70 °C, -20 – 70 °C
- Type of connector connection 1LC, LC, LC, LC
- Type of connector connection 2ST, ST, ST, ST
Tipas: Tinklo kabelis (patch) Izoliacija: LSZH Ilgis: 1 m Gamintojas: EFB Produkto kodas: O036..
